in association with James Eade and EXE Technology

2 days of intensive practical and theoretical control and power distribution training focused on rigging systems, with commonly used chain hoists and control platforms. Featuring EXE Drive and EXE Rise training equipment.

Suitable for novices as well as those with more experience of Rigging power and control systems.

Course runs 10:00 – 17:00 each day refreshments and a light lunch will be provided

Attendees will be invited to a complimentary meal out after the first day of the course.

Electrical safety in Rigging

Many will have experienced burnt-out contactors, failed windings or unexplained blown fuses. Are they faulty components, or issues from poor electrical design?

What about the risks with different Socapex pin-outs? Do you actually need RCDs on variable speed drives? How often should you ‘PAT test’ your kit? Does BS 7909 apply to rigging? Does it matter how long your rigging multi really is? Why are there always power issues with variable speed drives? What happens if a neutral fails?

For many in the rigging industry, power is a necessary sideline. But the safe and effective operation of motors, winches and similar all rely on effective protection and distribution. Come and find the definitive answers to these questions and more in this training workshop sponsored by Area 4 and hosted by Rigging Team.

Course outline

• Basic electrical theory overview/recap: Ohms law and how current, voltage and resistance interact.
• Electricity generation and the use of three- and single-phase supplies and the importance of phase balancing.
• The methods of protection from shock and overloads

► Practical demonstration: Measuring fault currents and voltage drop.

• Essential motor theory: Direct online starting, phase reversal, inverter drives.
• Control systems overview; Limit switches, up/down control, E-Stop operation.

► The above based on the EXE Rise suggested wiring schemes.

► Practical look at examples of controller functionality

► Practical look at wiring conventions

► Electrical standards and compliance notes

• A basic guide to power quality.
• Power measurements – a look at voltage drop and harmonics in demonstration equipment.
• A review of electrical legislation and appropriate standards including BS 7671 (the ‘wiring regs’) and BS 7909.
• Electrical maintenance and what is required for compliance with legislation.
• On-site checks and tests.

On completion of the course candidates will have:

• Comprehensive course notes
• A numbered certificate of attendance relating to the syllabus above
• An appreciation of their legal duties about power systems in automation
• A basic knowledge of how to use electrical equipment safely in lifting operations

Trainee requirements:

• Minimum 18 years of age on first day of course

Rigging Training FAQ’s:

What equipment do I need for the course?

We provide everything required except suitable work clothes and footwear.

Are there any entry requirements?

There are no entry requirements for this course.

Will the course make me a ‘qualified’ electrician or electrical system designer?

Attending a training course cannot make you competent or qualified but it will identify areas for improvement. In the UK, employers must provide adequate training for work activity where there are risks to your (or anyone else’s) health or safety because of the work you do. Undertaking training with Rigging Team may help to satisfy that requirement.

Do I need to send you any additional information?

Dietary and access requirements are covered on the booking form. However if you have any health conditions or feel there is anything we should be aware of before the course, please let us know.

How do I get course information once I have booked?

Joining Instructions will be emailed to you 3 days before the course is due to start. Please make sure you have added training@riggingteam.com to your safe sender list.
